An edge of the base is perpendicular to vP Construction (Fig631) 1 Draw the projections ofthe pyramid, assuming that it is resting on its base on HP and one edge of the base is perpendicular to VP 2 Redraw the front view so that the comer cl ofthe base is 25mm above xy forming final front view 3 Obtain the fmal top view by projection
The line through and perpendicular to both-To HP and one side of base is perpendicular to VP Draw its projections 2 A tetrahedron of 40 mm side rests with one of its edges on HP and perpendicular to VPHypotenuse (the side opposite to the right angle) Since sum of angles in a triangle is 180 0 and one angle is 90 0, the other two angles have to be necessarily acute(<90 0)angles The acute angles (two in number) are normally denoted
